Middle frequency transformer / High frequency transformercompact versions in the range of medium and high frequency at 1000 kVA to 50 kHz and 1 kVA to 200 kHz

overviewPDF datasheet

Coordinated winding goods – air- & water-cooled – for power electronics, manufactured with a resource-saving design

Advantages of the middle frequency transformers:

  • high-efficiency medium-frequency and high-frequency winding goods
  • execution in polyurethan – potting up to insulating material class F (without PU-Verguss to insulating material class H)
  • compact design
  • power range from 1 kVA
  • degree of protection up to IP 68 possible
  • Voltage up to 1500 V







Modern mf-magnetics for:

  • railway
  • welding technology
  • galvanic
  • power electronic
  • high power supply
